Description Overview Automatic box foaming machine with 7 chemical groups Machine dimensions: h 2000 x l 2300 x w 700 mm Square mold and round mold options available You can choose two molds with the machine: two square molds, two round molds, or a square mold and a round mold Additional mold sizes available to order It takes 20 minutes to make a bun Entire machine fits in a 40 foot hc container for shipment Specifications Square mold's foam size is w 2050 x l 2440 x h 1200 mm Round foam size is dia 1600 x h 2200 mm Foaming size of mould (maximum): l 2440 x w 2050 x h 1200 mm Foaming density: 10~60 kg/m3 Output of chemicals of each foaming (maximum): 180 l Power of mixing head: 7.5 kw Total power: 35 kw Has a 5 hp chiller for ppg and tdi Chemical Groups Chemical: ppg, tdi, mc, amine, tin, silicone and water (7 groups) Capacity of chemical tanks: ppg/3000 l, tdi/2000 l, mc/500 l, water/100 l, amine/tin/silicone/50 l Chemical tanks with machine Pumps Pumps: ppg/tdi/mc/amine/tin/silicone: us viking pump, water/taiwan pump Pumps are: ppg/tdi/mc/amine/tin/silicone: us viking pump, water/taiwan pump Control Plc control Touch screen operation panel Included Has two manual moulds with machine
