Karl Mayer, MRSS 56 SU, Width 130", 56 Bars, Liberty Superstructure

Karl Mayer, MRSS 56 SU, Width 130", 56 Bars, Liberty Superstructure

Description

  1. Overview
    1. Maker: Karl Mayer
    2. Type: MR(E)S 56 SU
    3. Width: 130 in
    4. Pattern wheels or chain L1 - L3 over chain
    5. SU aggregates: total 28 aggregates
  2. Bar Configuration
    1. Bars: 2 x ground + 2 picco bars installed
    2. 1 x ground bar available without guides
    3. Pattern bars: 52 installed
    4. Lycra bar: 1 x installed
  3. Superstructure And Take-Up
    1. Superstructure type: Liberty yes
    2. Take up type: standard
  4. Beam And Drive Specifications
    1. Quantity beam shafts: 3 x 70 mm
    2. Quantity EBA beam drive: 1 x EBA for ground, 1 x EBA for Lycra
    3. Pattern beams: 54 pcs
  5. Needle And Component Numbers
    1. Needle nos: 59.75 G1
    2. Clouser nos: C-24-76/4-14
    3. Sinker nos: S-24-98-59 / S 24-99-59
    4. Guide ref: AL-24-26-38
    5. Trick ref: F-24-76/4-14
    6. Pattern guides: F as it is in the machine
  6. Yarn Control System
    1. Yarn control system: Prokostop
