NovaStar, SB229, Pocket Spring Machine, 120 Springs/min, 33kW, 3600kg (New)

Description

Overview
1. SB229 pocket spring machine
2. Production capacity: 120 springs/min
3. One servo coiling head
4. Working principle: servo control
5. Spring shape: standard versions: barrel and cylindrical
Specifications
1. Air consumption approximately 0.25 m³/min
2. Air pressure: 0.6 to 0.7 mpa
3. Power consumption in total: approximately 33 kw
4. Voltage: 3ac 480 v
5. Frequency: 50/60 hz
6. Input current: 65 a
7. Cable section: 3*16 mm² + 210 mm²
8. Working temperature: +5 °c to +45 °c
9. Weight approximately 3600 kg
Non-Woven Fabric Consumption Material Data
1. Fabric density: 65~90 g/m²
2. Fabric width: 220-600 mm
3. Inner diameter of fabric roll minimum 60 mm
4. Outer diameter of fabric roll maximum 80 mm
Steel Wire Consumption Material Data
1. Wire diameter: 1.4 to 2.1 mm
2. Inner diameter of wire roll minimum 320 mm
3. Outer diameter of wire roll maximum 1000 mm
4. Acceptable weight of wire roll maximum 800 kg
Working Range (mm)
1. Option 1: wire diameter Ø1.4-1.6, spring waist diameter Ø45-55, pocket spring height 120-160
2. Option 2: wire diameter Ø1.6-2.1, spring waist diameter Ø55-70, pocket spring height 120-210
3. Option 3: wire diameter Ø1.6-2.1, spring waist diameter Ø60-75, pocket spring height 120-220
