NovaStar, SB233, Full Automatic Transfer Line for Inner Spring Units, Bonnell Spring Type, 12 Units/Hour, Max Width 2050mm (New)

NovaStar, SB233, Full Automatic Transfer Line for Inner Spring Units, Bonnell Spring Type, 12 Units/Hour, Max Width 2050mm

Description

  1. Overview
    1. Full automatic transfer line for inner spring units
    2. Model: SB233
    3. Production: 12 spring units per hour (spring unit size 1.5 m x 2 m)
    4. Spring type: Bonnell
  2. Specifications
    1. Spring diameter: 67 to 90 mm
    2. Steel wire diameter: 1.9 to 2.5 mm
    3. Spring height (can be customized): 100 to 180 mm (less than 80 mm needs to be customized)
    4. Spring coils: 4 to 7 coils
    5. Helical wire diameter: 1.3 to 1.4 mm
    6. Maximum spring unit width: 2050 mm
  3. Included Components
    1. Digital spring coiling machine
    2. Assemble machine
    3. Conveyor machine
  4. Operation
    1. Steel wire is produced to spring by spring coiling machine, then spring is sent to assemble machine by conveyor machine, finally spring is produced to spring unit by assemble machine.
    2. Automatic Bonnell inner spring units production plant adopts digital and modular design.
    3. You can choose digital spring coiling machine and assemble machine, this traditional semi-automatic production plant to produce small quantity spring unit and various specification spring unit.
    4. If require high efficiency production, like to produce large quantity of spring units with one specification, you can add one conveyor machine later with spring coiling machine and assembling machine to be full automatic Bonnell inner spring unit production plant.
    5. Can process up to 12 spring units per hour (spring unit size: 1.5 m x 2 m).
