Atac, ATC-J150, Sample Jigger Dyeing Machine, 300mm Width, 98°C, 2.2kW

Atac, ATC-J150, Sample Jigger Dyeing Machine, 300mm Width, 98°C, 2.2kW

Description

  1. Overview
    1. Sample jigger dyeing machine
    2. General material: Cr-Ni stainless steel
  2. Specifications
    1. Maximum temperature: 98°C
    2. Cylinder speed: maximum 25 meters per minute
    3. Maximum cylinder diameter: Ø 60mm x 400mm
    4. Maximum sample width: 300mm (10 to 35m fabric range)
    5. Heating type: resistance 2kW
    6. Liquor volume: 3 to 8 L
    7. Controller: 100 programs – 20 steps microprocessor
    8. Power supply: 220V, 50Hz
    9. Total power: 2.2kW
    10. Dimensions: 900mm x 740mm x 860mm
    11. Weight: 75kg
