NovaStar, MC184, Foam Hardness & Memory Foam Recovery Time Tester, 200kg Capacity, 500mm Stroke, 220V (New)

NovaStar, MC184, Foam Hardness & Memory Foam Recovery Time Tester, 200kg Capacity, 500mm Stroke, 220V

Description

  1. Overview
    1. Foam hardness tester and memory foam recovery time tester
    2. Used to test material compressed indentation hardness, such as sponge, foam, and other porous elastic materials
    3. Specimen is placed under a pressure plate that compresses it at a specific speed until it reaches the required national or international standard of concavity
    4. A load cell feeds the pressure to a computer which processes and displays the data
    5. Measures the indentation hardness of sponge, foam, and other materials
  2. Features
    1. Motor system: servo motor, servo driver, and high-precision ball screw
    2. Automatically saves results after test is finished, with manual filing option
    3. Software language: English
    4. Display method: PC
    5. Suitable for foam and sponge
    6. ILD test methods
    7. Thickness measurement of specimen (measures 100 mm)
    8. Machine load cell and elongation zero after 5 N load
    9. Compresses specimen 75 mm (75%) and returns immediately at speed of 50 mm/minute
    10. Holds for 1 minute
    11. Compresses specimen 25 mm (25%) at speed of 50 mm/minute and takes result after 20 seconds
    12. Report generation
  3. Main Technical Parameters
    1. Control and display: PC
    2. Sensor: Germany brand load cell
    3. Capacity: 200 kg
    4. Units: kg, N, lb
    5. Upper plate: diameter 200 mm, bottom fillet R1 mm
    6. Lower plate: 380 x 380 mm, holes diameter 6 mm, space 20 mm
    7. Maximum stroke: 500 mm
    8. Test speed: 0.1 to 1000 mm/minute
    9. Motor: servo motor
    10. Driver: Taiwan high-precision ball screw
    11. Power: single phase, 220 V, 50 Hz
    12. Dimension: 790 mm x 590 mm x 1010 mm
    13. Design standard: ASTM D test B1 and B2
