Description Overview Foam flammability tester used to test material flammability performance such as foam and interior materials of car. Complies with Fmvss571.302, Din7520, and Cal 117 standards. Specifications Flammability chamber material: stainless steel. Inner size (L x W x H): 385 mm x 204 mm x 360 mm. 10 ventilation holes with 19 mm diameter at the bottom, 13 mm wide ventilation slots around the walls of top chamber. Test stand: two U-shaped metal plates, size (L x W): 361 mm x 100 mm. Burning time: 0 to 99.99/s/m/h can be set free. Burning lamp: inside diameter of nozzle: 9.5 mm. Flame height: 38 mm. Metal comb: length 110 mm, with 7 or 8 smooth round teeth per 25 mm. Steel ruler: length 400 mm, accuracy: 1.0 mm. Power: single phase, 220 V, 50 Hz (or as per client request).
