NovaStar, MS370, Crystal Pleating Machine, 1000mm Width, 10-105mm Pleating Height, 20-80 Pleats/Min (New)

NovaStar, MS370, Crystal Pleating Machine, 1000mm Width, 10-105mm Pleating Height, 20-80 Pleats/Min

Description

  1. Overview
    1. Crystal pleating machine
    2. Model: APE-250-100
    3. For air filters, shades, curtains, etc.
  2. Specifications
    1. Useful width: 1000 mm
    2. Motor: 1 HP
    3. Pre-heating heater: 2.0 kW / 2.5 kW
    4. Machine dimension: (L) 2000 mm x (W) 1800 mm x (H) 1600 mm
    5. Pleating height: 10 mm ~ 105 mm
    6. Working speed: 20 ~ 80 pleats per minute
    7. Operation temperature: 130 ~ 180 °C
    8. Net weight: 780 kg
  3. Features
    1. Top/bottom heating and forming system
    2. Coiling table
    3. Pleat counter
    4. Top/bottom pleating knives
    5. AC reversible motor
    6. Control box
