Bruckner, Stenter Machine, 2400mm Width, Combined Pin-Clip Chain, Steam Heated

Description

Overview
1. Bruckner stenter machine
2. Combined pin-clip chain
3. For 100% cotton or poly/cotton fabric
4. Suitable for sheeting, sateen and twill fabric
Specifications
1. Straightening range: minimum 600 mm, maximum 2400 mm
2. Speed: 60 m/min (for fabric 150 g/m²)
3. Fabric width: 2400 mm
4. Maximum fabric density: 250 g/m²
5. Fabric weight: 100 to 250 g/m²
6. Speed range: 6 to 120 m/min
Heating and Steam
1. Steam heated
2. Steam requirements: 2000 kg/hour
Chamber Configuration
1. Entry chamber length: 3 meters
2. Exit chamber length: 3 meters
3. 4 drying chambers (3 meters long each)
4. Cooling zone length: 1500 mm
Stenter Entry Equipment
1. Frame with fabric guiding rollers
2. Compact CE straightening and centering device
3. With 2 spiral rollers and 2 guiding rollers with rubber coating
4. With electro-optical sensor Fluo-E to automatically center fabric
Impregnating Padder
1. Kleinwefers Bicoflex impregnating padder
2. Used for treating fabric with stiffeners
3. Roll width: 2600 mm
4. Maximum fabric width: 2400 mm
Included Components
1. Mahlo weftstraightener
2. Othomat RFMC 10 with LCD display
3. 1 pair of edge straighteners model LA 5302
4. Infrared drying device burner BKT
5. High capacity ionizing device Antistat
6. Batcher at exit
