MAN B&W, 16V 32/40, 2001, 53MW Diesel Generator Power Station, 7 Units, 750 RPM, 11 kV

MAN B&W, 16V 32/40, 2001, 53MW Diesel Generator Power Station, 7 Units, 750 RPM, 11 kV

Description

  1. Overview
    1. Diesel engine with auxiliaries
    2. Total plant: 7 units
    3. Manufacturer: Man B&W
    4. Type: 16V 32/40
    5. Year: 2001
    6. Start electricity production: 2002
    7. Out of service: 2003 (partly operation 2008+2009)
  2. Diesel Engine Specifications
    1. Power output gross: 7.680 MW each
    2. Speed: 750 rpm
    3. Fuel type: fuel oil number 6, diesel (heavy fuel oil HFO) or LFO (light fuel oil)
  3. Alternators
    1. Make: ABB
    2. Type: AMG 1120MR08
    3. Power output gross: 9.330 MVA each
    4. Terminal voltage: 11 kV/50 hertz
    5. Power factor (cos phi): 0.8
  4. Black Start-Up Diesel Generator
    1. Make: Iveco
    2. Type: Fi-250
    3. Speed: 1500 rpm
  5. Black Start-Up Alternator
    1. Make: Mabex
    2. Type: AC1434C2
    3. Power output: 250 kVA
  6. Transformers and Switchgear System
    1. Step-up transformers (alternator main transformers): 2 units
    2. Make: Best
    3. Power output: 50 MVA
    4. Ratio in/out: 11 kV/34.5 kV
    5. Tap changer: on load automatic regulation
    6. Connection: Ynd 11
    7. Cooling system: ONAN
    8. Switchgears: 11/0.4 kV and 24 V DC-systems (Fa. Kuhse, Germany)
  7. Condition and Configuration
    1. Diesel engine and alternator are fixed on a common base frame as one transport unit, flexible coupling included
    2. The units have been maintained by the manufacturer throughout the lifetime a acc. service program
