Monforts, Sanforiser, 1995, 2400mm Width, Mahlo Weft Straightener, 10m Clip Tenter

Description

  1. Overview
    1. Monforts sanforiser
    2. Year: 1995
    3. Max fabric width: 2400 mm
    4. Exceptionally well equipped
  2. Specifications
    1. Rubber belt width: 2460 mm
    2. Palmer cylinder diameter: 2400 mm
    3. Endless felt blanket width: 2470 mm
    4. Clip tenter length: 10 m with steaming field
    5. Palmer calender with 240 cm diameter cylinder
    6. Blanket drying cylinder
    7. Cooling cylinder, water cooled
    8. High entrance frame with one pair KF10 guiders on a screwed width adjustment shaft
    9. Compensator and tension control rails
    10. Driven draw roller
    11. Compensator
    12. Mahlo bow and skew weft straightener, 4 heads
    13. Rubber belt shrinking machine
    14. Draw rollers
    15. Scray for non-stop batching
    16. Exit frame with draw roller
    17. Surface driven a-frame batcher and plaiter
  3. Condition
    1. Rubber belt is in almost as new condition
    2. Suitable for processing a wide range of fabrics from lighter weight apparel fabrics to denim, twills and bed sheetings
  4. Included
    1. Mahlo weft straightener
    2. 10 m long clip tenter
