Stentex, Stentotherm 3300 E, 1996, Multilayer Stenter, Working Width 885 to 2200mm, 5 Chambers, Thermal Oil Heating

Name: Stentex, Stentotherm 3300 E, 1996, Multilayer Stenter, Working Width 885 to 2200mm, 5 Chambers, Thermal Oil Heating
Brand: Stentex
SKU: R-1562

‹ Go Back Next Product ›

Description

Overview
1. Stentex multilayer stenter for drying and heat setting
2. Year: 1996
3. Model: Stentotherm 3300 E
4. Suitable for woven fabrics
Specifications
1. Working width: 885 to 2200 mm
2. 5 chambers in 2 floors and 3 passages
3. Vertical pin chain with anti-depinning device
4. Thermal oil heating
Composition
1. Entry from a-frame or trolley
2. J-scray
3. Dogal fabric and Bianco centering device
4. 2 bowls finishing and squeezing padder plus preparation kitchen
5. 2 Evac suction systems before and after the padder
6. Bianco weft straightener type FDC 3 with 6 readers
7. Entry field with E+L Tandematic
8. Entrance bridge with controls for oil heaters 5+5
9. Stentomatic controller 2100 with touch screen
10. Steam pre-heating system on the entry

Additional Specifications

Specifications

Applications

Woven fabrics

Included

['Entry from A-frame or trolley', 'J-scray', 'Dogal fabric and Bianco centering device', '2 bowls finishing and squeezing padder + preparation kitchen', '2 Evac suction systems before and after the padder', 'Bianco weft straightener type FDC 3 with 6 readers', 'Entry field with E+L Tandematic', 'Entrance bridge with controls for oil heaters 5+5', 'Stentomatic controller 2100 with touch screen', 'Steam pre-heating system on the entry', 'Delivery to A-frame or trolley', 'Fire extinguisher system', 'Fabric humidity system Mahlo Textometer', 'Air cooling zone', 'Inplan Ingenieurtechnic boiler 1.500.000 kcal with fuel burner + all accessories']
