NovaStar, DG480, High Temperature Infrared Ray Sample Dyeing Machine, 24 Beakers, 4.5kW
Scroll to zoom
100%
Description
Overview
High temperature infrared ray sample dyeing machine
Model: DG480 (fourth generation)
Developed in 2009 with a table type design; bottom bracket is optional
Developed from FAD-18P; running method changed from circuit to tumble for ultra low liquor-ratio of 1:4 to 1:30 and 5g to 50g, with 720-degree beaker rotation
Suitable for dyeing woven fabrics, knitted fabric, yarn, and wool to achieve flat and uniformly dyed samples
Features
Equipped with LCD-displayed computer TC2008 for real-time monitoring
Controlled by frequency converter and automatic clockwise/anticlockwise rotation devices
Liquor in beakers fluctuates with adjustable rotation speed for more uniform dye uptake
Can set 99 programs and 99 steps
Specifications
Beaker volume: 200cc, 350cc, 420cc, or 1000cc; 18 or 24 beakers in SS 316L material
Heating method: infrared heating tube
Heating medium: aluminum metal conducts
Dyeing temperature range: ambient to 140°C
Temperature accuracy: ±0.5°C
Heating rate: 0.2 to 4°C
Cooling method: air cooled
Rotator type: tumble (clockwise and anticlockwise running ability)
Rotating speed: 0.2 to 60 rpm
Power: 4.5 kW
