Made of high quality stainless steel with mirror surface which is corrosion-resistant
Automatic temperature control system by hot air circulation, using two groups of imported temperature controller with digital display P.I.D regulator; the hot air spreads uniformly, steadily and accurately
Function of adjusting the cloth width
Equipped with automatic cloth dropping device and vessel for placing the cloth (note: the pin frame cannot be used if you use automatic cloth dropping device)
Using pin chain: feeding → dwelling time which is controlled by regulator → cloth drop
Using pin frame: feeding → dwelling time which is controlled by regulator → getting through the oven and stop
Specifications
Temperature range: 20℃ to 250℃ with accuracy of ± 1℃
Three groups of 1/6 hp fan motors
Main motor (1 hp) for chain drive
Maximum working width is from 150 mm to 350 mm
Dwelling time can be set from 20 seconds to 6 minutes
Overall dimension: 2410 x 940 x 1390 mm (L x W x H)
