Description Overview Main technical features Drawings: Sm 0996 - Sm 0996/1 Documentation in English or in symbols Metric system Color: Ral 9002 Web and Reel Specifications Max web width: 1350 mm Working width: 1300 mm Min web width: 800 mm Idle roll: 1450 mm Coating cylinder circumference: 650 mm Max reel diameter at unwinding (1st) for paper and cardboard: 1000 mm Inner core diameter: 3 in - 6 in Max reel diameter at unwinding (2nd) for alu foil 6-7 my: 600 mm Inner core diameter: 3 in - 6 in Max reel diameter at unwinding (3rd) for dry lamination: 800 mm Inner core diameter: 3 in - 6 in Max reel diameter at rewinding of laminated material: 1000 mm Inner core diameter: 3 in - 6 in Speed and Performance Production speed up: 200 mt/' (speed depends largely on the materials used and on the final product) Max mechanical speed: 300 mt/' Heating and Electrical System Heating system: Electric system Supply voltage: 220/380 V - 50 Hz - 3ph Regulation of electric installation: Ex-proof cei Compressed air: 6 bar Noise level: 85 db (a) Accident prevention: Ispels regulation Energy Data Installed electric power: 400 kw approx. Absorbed electric power: 70% Max air temperature: 120 °c Max air volume: 18.000 m3/h Air recirculation up: 80% Wet Lamination Processes Material to coat: aluminium 6,35-20 my, pet 12-40 my, bopp 15-40 my Material to laminate: paper 40-100 gsm, cardboard up to 260 gsm Dry Lamination Processes Material to coat for self-adhesive labels: siliconed paper 60-80 gsm Material to laminate: paper 120 gsm, pvc 25-60 my, bopp 40-60 my, pe 40-80 my
