NovaStar, WN303, Secondary Ring Twister, 40 Spindles, 204mm Ring Diameter, 300mm Lift (New)

NovaStar, WN303, Secondary Ring Twister, 40 Spindles, 204mm Ring Diameter, 300mm Lift

Description

  1. Overview
    1. Ring twister
    2. Model: RT-722
    3. 8 spindles per group (5 groups)
    4. Quantity of spindle: 40 (adjusted)
  2. Specifications
    1. Lifting movement of traveler ring: 300 mm
    2. Speed of spindle: 1800 to 2800 rpm
    3. Diameter of roller: 57 mm
    4. Distance of spindle: 280 mm
    5. Power of motor: 380 VAC, 3 phase, 50 Hz, 15 kW (or as per customer)
    6. Diameter of traveler ring: 204 mm
    7. Twisting direction: Z or S
    8. Scope: 21 counts 5-180 ply yarn or 850-15000 fiber
    9. 36 tex 21-70 ply twine
    10. Bobbin size: 175 mm x 300 mm
  3. Dimensions and Weight
    1. Overall dimension: 7.07 x 1.58 x 2.27 m
    2. Machine weight: 6600 kg
