Description

  1. Overview
    1. D-2220 sample centrifugal hydro-extractor is specially designed for extracting at high performance with minimum consumption of energy and time.
    2. All materials used in the production of the machine provide strong and reliable construction.
    3. Parts contacting directly with extracted garments are manufactured of AISI 316L quality stainless steel.
    4. The outer body and lower chassis are made of iron.
    5. Strong resistance to rusting, all kinds of harmful movement, water and humidity is gained by the usage of best quality material in every part of the machine, produced by stainless steel.
    6. This machine is built in accordance with the CE-73-23-CEE norm and is entirely manufactured in Turkey in Danis production facilities.
  2. Specifications
    1. Machine capacity: 20 kg
    2. Rotation speed: 0-1350 rpm (variable)
    3. Installed power: 2.2 kW
    4. Capacity of extracting efficiently 20 kg of wet garment in 4 minutes, due to its rotating speed of 1350 rpm.
    5. Working time: 4-10 min
    6. Time adjust by electronic panel.
    7. Rotation speed: 1-1350 rpm
  3. Construction and Materials
    1. Electro-welded steel structure, sandblasted and painted with special rustproof paint.
    2. AISI 316L stainless steel casing, fixed to the frame.
    3. All parts in contact with water are produced by stainless steel.
    4. Drum made by stainless steel.
    5. Door made by stainless steel and automatically opening and closing.
    6. Manual door with porthole for sampling and double automatic locks.
  4. Electrical and Control System
    1. Siemens, Finder, Telemecanique branded electrical components.
    2. This machine is supported with special electric, pneumatic and hydraulic systems.
    3. The electric system is protected by a fan against over-heating and humidity.
    4. This machine is controlled by the electronically controlled panel with software entirely developed by Danis engineers in order to control all the machine functions and machine process fastly and easily.
