NovaStar, TL155, Lab Rotor Spinning Machine, 35000rpm, PLC & Touch Screen (New)

Description

Overview
1. Laboratory rotor spinning machine can complete spinning yarn without using a spindle, ring or traveler and achieve faster speed, higher productivity and less cost than ring spinning.
2. After the sliver is fed into the machine, it is opened by the carding roller, and then goes into the rotary cup.
3. After twisting, the open-end yarn is formed and comes out, wrapped on a paper bobbin.
4. There is no need for roving frame or cone winding machine.
5. This machine has small dimension with PLC and touch screen control, simple to operate and adjust, so as to suitable for schools, research institutes and R&D centers.
Specifications
1. Suitable fiber type and length: cotton, 22 to 42mm
2. Control mode: PLC and touch screen
3. Number of rotor: normal: 1 rotor, or as specified
4. Rotor speed: 35,000rpm
5. Carding roller speed: 6,000rpm
6. Coiling speed: 20 to 110m/min
7. Draft range: 30 to 250
8. Power supply: AC220V, 50Hz 1.2kW
9. Package dimension: 1400 × 900 × 1800mm (L×W×H) for 2 rotors
10. Net/gross weight: 500/600kg for 2 rotors
Features
1. Mini-type design, easy to clean and maintain.
2. PLC and touch screen, easy to learn and operate.
3. Use touch screen as man-machine interface, digitally set test parameters and show machine run state on the touch screen.
4. The speeds of rotary cup and carding roller meet general requirements of factories.

HS code	8445.20

Coiling Speed	20-110 m/min

Control system	PLC & Touch Screen
Suitable Fiber Type And Length	Cotton, 22 to 42mm

Motor power	1.2 kW
Voltage	220 V
