NovaStar, FN406, CNC Roller Transverse and Vertical Cutting Machine, 1250mm Width, 100mm Thickness, 4kW (New)

NovaStar, FN406, CNC Roller Transverse and Vertical Cutting Machine, 1250mm Width, 100mm Thickness, 4kW

Description

  1. Overview
    1. Cuts sheet and rolled foam
    2. Cnc roller transverse and vertical cutting machine
    3. Machine is fully automatic and can cut sheet or rolled foam
    4. Set length and quantity and machine works automatically
  2. Specifications
    1. Cutting width: 20 to 1250 mm
    2. Cutting thickness: 3 to 100 mm
    3. Motor power: 4 kW
    4. Voltage: 480 volts, 3-phase, 60 Hz (or as per customer)
    5. Dimensions: 2000 x 1500 x 1300 mm
    6. Net weight: 1200 kg
  3. Controls and Features
    1. Servo motor feeding
    2. Touch screen display and operations
    3. Controlled by plc
