Widely used in various types of metal, rubber, plastics, leather shoes, clothing, textile, insulators, wire and cable, terminals and other types of materials, testing the tensile, tearing and peeling, compressive strength, bending shear and three point bending, elongation, sponge, foam and other porous elastic material of the indentation hardness and compression calculation of pressure ratio… and other physical testing performance.
Design Standard
ISO 2439, ASTM D 3574
Standard Features
Control and display: computer
Sensor: load cell
Capacity: 200 kg
Unit: kg, N, lb
Up plate: diameter 200 mm, bottom fillet R1 mm
Low plate: 380 x 380 mm, holes diameter 6 mm, space 20 mm, max stroke 200 mm
Max stroke: 1200 mm (include fixture)
Test speed: 0.1~500 mm/min
Load decomposition degree: 1/250000
Load accuracy: less than 0.5%
Motor: servo motor
Driver: Taiwan high precision ball screw
Power: single phase, 220 V, 50 Hz
Weight: 170 kg
Dimension: 510 x 880 x 1490 mm
Included Accessories
One computer with software
Sponge tensile clamp set
Sponge pressure depression pressure plate
