Propane gas fired, fully modulating burner with 8:1 turndown
Sized for installation at 7000 feet above sea level
Item 002: Vapor Modulatic-Style Steam Superheater
Model no. H6-4322-SHK-DR
Sized to raise 15,870 pounds per hour of 250 psi saturated steam to 481° f superheated steam
350 psi, 600° f design
Propane gas fired, fully modulating burner with 5:1 turndown ratio
Sized for installation at 7000 feet above sea level
Included with Superheater
1 Siemens LMV51 flame safeguard and linkageless burner control system with AZL52 display module
1 stack thermocouple and alarm
1 pre-piped, wired, and mounted FM gas train for 2-5 psi max gas supply pressure with main and pilot gas regulators
1 main steam stop valve (inlet and outlet)
1 steam safety valve
1 NEMA 12 control panel enclosure complete with control system and all required safety controls, motor starters, and control voltage transformer for 460 volt, 3-phase, 60 Hz electrical supply
1 ASME section 1 approval
