Description Overview Year: 2010 Working width: 1900 mm Number of colors: 6 Number of prewinders per set: 3 Number of frames supplied: 4 Number of warp stop bars: 6 Number of hedles supplied per set: 5000 Number of droppers supplied: 5000 Number of reed supplied: 1 Number of warp beams supplied: 1.1 Number of cloth rollers supplied: 1.1 Shedding Mechanism Type: Cam Motion make: Staubli Motion model: 1661 Motion type: Mechanical Motion capacity: 6 Motion installed capacity: 6 Selvedge and Easing Selvedge type: Rotary leno Easing motion: Available Beams and Rollers Number of back rest rolls: 1 Warp beam diameter: 800 mm Take-Up and Let-Off Cloth take-up type: On loom Take-up motion: Electronic Let-off motion: Electronic Temple and Detection Temple type: Normal Filling detection sensor type: Front of reed Condition Looms stopped on mill floor Test run possible
