Gartemann & Hollmann G&H-533 Tuber and Windmoller & Holscher AD Bottomer, 1971, Refurbished 2014, 4 Colors, 5 Ply

Gartemann & Hollmann G&H-533 Tuber and Windmoller & Holscher AD Bottomer, 1971, Refurbished 2014, 4 Colors, 5 Ply

Description

  1. Item 001: Tuber G&H-533
    1. Year of production: 1971
    2. Refurbished in 2014
    3. Stepped cut
    4. Inline printer, 4 colors
    5. Number of ply: 5
    6. Paper density: from 60 to 100 gsm
    7. Tube width: 350 to 550 mm
    8. Tube length: from 640 to 1100 mm
    9. Roll width: up to 1120 mm
    10. Maximum coil diameter: 1000 mm
    11. Number of rolls: maximum 5 rolls
    12. Gluing station: mechanical
    13. Speed: 60 tubes per minute
    14. Weight: 5000 kg
    15. Dimensions: 14600 x 2200 x 2200 mm
    16. There is no transystem between tuber and bottomer
  2. Item 002: Bottomer Windmöller & Hölscher AD
    1. Year of production: 1971
    2. Refurbished in 2014
    3. Open mouth sacks and valve sacks
    4. Width of the sack: 350 to 550 mm
    5. Bottom width: 100 to 170 mm
    6. Open mouth sack length: 560 to 1020 mm
    7. Length of valve sack: 490 to 940 mm
    8. Valve length: 180 to 285 mm
    9. Number of valve units: 2 pcs
    10. Number of valve layers: 2 layers
    11. Knot of formation of a bottom and insert of the valve of a paper bag
    12. Speed: 60 bags per minute
    13. Capacity of bags: at the same time there are 28 bags in the line
    14. Perforation: 4 rows through at the top of the bag and/or on each layer (including a polyethylene layer along the entire length with an interlayer displacement)
    15. Number of printing colors: without the possibility of printing on the cover sheets
    16. Preliminary system of printing on paper: without the possibility of printing on the cover sheets
    17. Suitable for bags for cement, dry building mixes, gypsum, food solids, chemicals, charcoal, animal feed, seeds
    18. Open bag for coal 2.5 / 3 / 5 / 10 kg, for food and non-food bulk materials up to 25 kg
    19. Closed with valve from 15 kg to 50 kg
    20. Power consumption: up to 100 kW
    21. Voltage: 380 V (50 Hz)
    22. Dimensions: 28000 x 2500 x 2500 mm
    23. Weight: 22,000 kg
