Description Overview Application: Transport and mounting of full and half beams Unloading big batches from batching motion and rolling off onto the floor or e.g. pallets Specifications Carrying capacity: 2000 kg up to 3000 kg Cradle diameter: 1000/1250/1500 mm Max. carrying capacity: 2000/3000 kg Min. cradle length L = 1200/2500 mm Advantages Truck can be used without limitation such as cradle truck e-khum Safe rolling over of big batch from batch winder and rolling off onto the floor Safety switching for roll over height of batching motion Specifications Required for Inquiry Machine width MB Half beams and/or full beams Max diameter of warp beam and/or big batch D Height of batching motion Max weight of batch roll
