Raymond, 5057 High Side, 1968, 50 inch Diameter, 5 Rollers, 100HP Mill Power

Description

Overview
1. Raymond 5057 high side roller mills
2. Brand: Raymond
3. Model: 5057 high side
4. Style: Vertical roller mill
5. Year: 1968
Specifications
1. Mill size: 50 in diameter (1270 mm)
2. Roller: 5 rollers per mill
3. Feed size: 10-40 mm (½" to 1½")
4. Discharge size: 10% r2000 micron (90% minus 10 mesh) to as fine as 0.002% r44 micron (99.998% minus 325 mesh)
5. Nominal airflow: 10,000 cfm (16,900 m³/hr)
6. Max airflow: 12,000 cfm (20,300 m³/hr)
7. Water evaporation: 1,800 lbs/hr
8. Recommended fan power: 60 hp (45 kW)
9. Recommended mill power: 100 hp (75 kW)
10. Recommended classifier power: 30 hp (22 kW)
Condition
1. Used, reported in good condition
Shipping
1. Requires 2 to 3 loads (vans/truck trailers) to ship each unit

Capacity	10000 CFM nominal airflow
Discharge Size	10%R2000 micron to 0.002%R44 micron

Dimensions	50 in diameter (1270mm)

Max Airflow	12,000 CFM
Water Evaporation	1,800 lbs./hr.

Recommended Classifier Power	30 HP (KW)
Recommended Fan Power	60 HP (KW)
Recommended Mill Power	100 HP (KW)
