SMB, FD 10-4, 2014, 4 Colors, 600mm Printing Width, Gearless, UV Drying

SMB, FD 10-4, 2014, 4 Colors, 600mm Printing Width, Gearless, UV Drying

Description

  1. Overview
    1. Machine manufacturer: SMB
    2. Model: FD 10-4
    3. Year: 2014
    4. Type of inks: UV
    5. Number of colors: 4
    6. Geared or gearless: Gearless
    7. Cl or stack: CL
  2. Specifications
    1. Max. web width: 650 mm
    2. Max. printing width: 600 mm
    3. Min. to max. printing repeat: 300 to 800 mm
    4. Max. mechanical speed: 250 m/min
    5. Materials: PET, OPP, ALU and laminates 20 to 150 µm
    6. Unwind type: Single
    7. Max. unwind reel diameter: 1000 mm
    8. Rewind type: Single
    9. Max. rewind reel diameter: 1000 mm
    10. Video camera: Yes
    11. Corona treater: Yes
    12. Number of aniloxes: 13
    13. Number of sleeves: 104
  3. Condition
    1. This printer built by German manufacturer SMB is a relatively new machine.
    2. Special feature: equipped with UV drying, which is not very common with CI flexo presses.
    3. With gearless technology, it is a modern machine.
