Description Overview Twisted handle paper Bag machine Block Bottom BS129 carrier Bag machine Year: 2023 Working from the roll, in-line twisted loop handle attachment unit for twisted paper handles Varying greatly sizes at a high speed, thus is especially suitable for being applied for shopping industry A turnkey solution for your paper Bag business Specifications Paper Bag cutting length (c): 380 to 650 mm (380 to 770 mm) Paper Bag width (w): 220 to 540 mm Paper Bag Bottom width (h): 80 to 250 mm Paper thickness: 90 to 170 g/m² Max. paper Bag speed: 120 pcs/min Paper roll width: 630 to 1510 mm Paper roll diameter: 1200 mm Inner diameter of the paper roll: 76 mm Handle rope height: 110 to 120 mm Handle rope diameter: 4 to 6 mm Handle sheet length: 190.5 mm Handle sheet width: 80 to 100 mm Machine supply: 480 V, 60 Hz, three-phase, four wires Power: 39 kW Weight: 20,000 kg Dimension: l1 4000 x w 6000 x h 3100 mm Dimensions: 14000x6000x3100mm
