Operation/automatic/shutdown control, speed regulation, voltage regulation, local and remote emergency shutdown, Modbus communication
Digital indication items include: engine speed RPM, operating hours, oil pressure, coolant temperature, start counter, system DC voltage, line voltage, phase voltage, average voltage, phase current, frequency
Unit protection and alarm/shutdown include: control switch not in automatic mode, low lubricating oil pressure, high coolant temperature, low coolant level, overspeed, excessive turning
Parallel Function
Automatic parallel connection: in automatic parallel mode, the EMCP 4.4 controller automatically adjusts voltage and frequency; when synchronized, it provides a signal to close the generator circuit breaker
Manual parallel connection: operator manually adjusts voltage and frequency; when synchronized, operator initiates circuit breaker closing command; has 3-phase synchronization check function to prevent out-of-phase parallel connection
Synchronous check mode: EMCP 4.4 controller automatically adjusts voltage and frequency but does not provide a signal to close the circuit breaker; operator initiates closing command; has 3-phase synchronization check function
Soft loading/unloading: when distributing loads, soft loading and soft unloading reduce instability and equipment risks by increasing or decreasing load in a controlled manner before controlling closure or disconnection of the development motor circuit breaker
Technical Data
Low BSFC
Generator set rated power at 0.8 PF: 2275 kVA
Generator set rated power with fan: 1820 ekW
Fuel consumption with fan, 100% load: 470.8 L/hr
Fuel consumption with fan, 75% load: 346.3 L/hr
Fuel consumption with fan, 50% load: 239.2 L/hr
Cooling system air throttle (system): 0.12 kPa
Cooling system air flow rate (maximum value at rated speed of radiator configuration): 2254 m³/min
Engine/coolant capacity with radiator/expansion tank: 380.2 L
Engine coolant capacity: 233 L
Radiator coolant capacity: 131 L
Inlet combustion intake air flow rate: 151.7 m³/min
Exhaust pipe gas temperature: 554.3°C
Exhaust flow rate: 443.2 m³/min
Exhaust pipe flange size (inner diameter): 203.2 mm
Exhaust system back pressure (maximum allowable value): 6.7 kPa
Heat dissipation of coolant (all): 751 kW
Heat dissipation of exhaust pipe (all): 2080 kW
Heat dissipated from the engine to the atmosphere: 166 kW
Heat emitted from the generator into the atmosphere: 94 kW
Alternator motor starting capacity at 30% pressure drop: 3167 skVA
Alternator frame: Y5060H4
Alternator temperature rise: 105°C
Lubrication system oil pan with filter/filling: 401.3 L
