Miura, LXH-300, Gas-Fired Steam Boiler, 300 BHP, 30 PSI

Miura, LXH-300, Gas-Fired Steam Boiler, 300 BHP, 30 PSI

Description

  1. Overview
    1. Miura industrial high-pressure, gas-fired model LXH-300 steam boiler.
    2. Capacity of 300 boiler horsepower (BHP).
    3. Rated 30 psi.
    4. Producing an equivalent output of 6900 to 10,350 lb/hr and a maximum heat output of 10,043 mm Btu/hr, with a heating surface area of 613 ft² and a turn-down ratio of 4:1 (25%).
    5. The boiler is compatible with natural gas or propane, requiring a fuel supply pressure of 3-5 psig and a heat input of 11.678 mmBtu/hr, delivering an efficiency of 86%.
    6. It maintains flue gas excess oxygen at 5.0% with a flue gas temperature of 230°F.
    7. Emissions include NOx levels of 20 ppm for natural gas and 25 ppm for propane, while CO emissions remain at 100 ppm.
    8. The boiler has a shipping weight of 11,800 lbs and an operational weight of 13,000 lbs, with an operational water content of 140 gallons and a fully flooded capacity of 300 gallons. Its dimensions measure 63 in width, 153 in length, and 127 in height.
  2. Specifications
    1. Brand: Miura
    2. Model: LXH-300
    3. Boiler horsepower (BHP): 300
    4. Steam output: 6,900 - 10,350 lb/hr
    5. Maximum heat output: 10.043 mmBtu/hr
    6. Heating surface area: 613 ft²
    7. Fuel compatibility: natural gas or propane
    8. Fuel supply pressure: 3-5 psig
    9. Heat input: 11,678 mmBtu/hr
    10. Boiler efficiency: 86%
    11. Turn-down ratio: 4:1 (25%)
    12. Flue gas temperature: 230°F
    13. Excess oxygen in flue gas: 5.0%
    14. NOx emissions: 20 ppm (natural gas), 25 ppm (propane)
    15. CO emissions: 100 ppm
    16. Operational water content: 140 gallons
    17. Fully flooded capacity: 300 gallons
    18. Shipping weight: 11,800 lbs
    19. Operational weight: 13,000 lbs
    20. Dimensions: width 63, length 153, height 127 in
    21. Weight: 5352
  3. Condition
    1. Used Miura LXH-300 steam boiler is a high-efficiency, high-pressure water tube boiler designed for industrial steam generation.
    2. With a capacity of 300 boiler horsepower (BHP), it produces an equivalent steam output of 6,900 to 10,350 lb/hr, delivering a maximum heat output of 10,043 mmBtu/hr.
    3. Built for versatile fuel compatibility, this boiler operates on natural gas or propane, requiring a fuel supply pressure of 3-5 psig.
    4. It provides an efficiency of 86%, featuring a 4:1 turndown ratio (25%) for energy savings and responsive load adjustments.
    5. With a flue gas temperature of 230°F and NOx emissions of 20 ppm (natural gas) or 25 ppm (propane), this Miura boiler meets strict environmental regulations while maintaining a compact footprint and fast start-up capabilities.
  4. Applications
    1. Industrial manufacturing - steam generation for production lines.
    2. Food and beverage processing - steam heating for sterilization, cooking, and brewing.
    3. Pharmaceutical and chemical industries - clean steam production for sensitive processes.
    4. Textile and paper mills - process heating and drying applications.
    5. Hospitals and healthcare facilities - reliable steam supply for sanitation and heating.
  5. Compatible Products
    1. Steam distribution systems.
    2. Heat exchangers and condensate recovery systems.
    3. Industrial autoclaves and sterilization chambers.
    4. Process heating and steam injection systems.
    5. Energy-efficient steam plant applications.
  6. Product Details
    1. Used Miura steam boiler.
    2. LXH-300 gas-fired boiler for sale.
    3. 300 BHP high-pressure steam boiler.
    4. Industrial water tube boiler.
    5. Natural gas and propane steam boiler.
    6. Used Miura LXH-300 steam boiler for sale.
    7. High-pressure water tube boiler with 10,350 lb/hr capacity.
    8. Energy-efficient gas-fired steam boiler with 86% efficiency.
    9. 300 BHP industrial boiler for manufacturing and processing.
    10. NOx compliant natural gas boiler for industrial applications.
    11. Used Miura LXH-300 high-pressure steam boiler with 6,900-10,350 lb/hr output.
    12. Industrial water tube boiler with 300 BHP and 4:1 turn-down ratio.
    13. Energy-efficient gas-fired steam boiler with low NOx emissions (20 ppm).
    14. Miura LXH-300 steam boiler for food, pharmaceutical, and industrial use.
    15. Compact high-performance steam boiler for manufacturing and process heating.
