Description Turbine Specs A05 Siemens lightweight aero-derivative gas turbine package PGAS requirements - modular DLE turbine Max flow rate per turbine: 40 to 60 MCF per hour Supply pressure: 270 to 280 psi Min gas temperature: 36 °F above dew point Max gas temperature: 200 °F Min/max LHV: 800 - 1100 BTU Wobbe index: 1170 ±130 BTU/SCF Max liquids: no liquids/moisture/oils permissible Max particle size: 1 pm Ethane content: <10% Gas Requirements - Modular WLE Turbine Max flow rate: 40 to 60 MCF per hour Supply pressure: 270 to 280 psi Min gas temperature: 3 °F above dew point Max gas temperature: 200 °F Min/max LHV: 600 to 2000 BTU Modified Wobbe index: 1040 to 1300 BTU/SCF Max liquids: no liquids/moisture/oils permissible Max particle size: 1 pm Condition and Warranty 2 packed with 5 units and the other with 8 units 2 units are unused and 3 units have between 419 to 7594 hours recorded All come with one year Siemens warranty Item 002 New unused SGT-A05 KB7-S 5.4 MW 50 Hz Natural gas/liquid fuel For immediate delivery With one year Siemens warranty SpecificationsWeight: 58000Dimensions: 15240x2750x3660mm
