Pedersen, 601M-16S, Hydraulic Press, 100 Ton, 1000x1600mm, Rebuilt
Scroll to zoom
100%
Description
Overview
Hydraulic press
Brand: Pedersen
Model: 601M-16S
Full head press
A four-post hydraulic press producing 100 metric (110 U.S.) tons of cutting force, with two cylinders mounted over cross members linked end to end with torsion bars
This mechanical balancing system ensures that the maximum cutting force of the press can be delivered across the entire cutting area of the machine, and keeps the bed and bridge parallel even under asymmetrical (unbalanced) loads, which, in turn, reduces mis-cuts and damaged parts and provides for longer tool and pad life
This hydraulic press can deliver its total force during the entire down stroke
Specifications
Cutting force: 100 metric (110 U.S.) tons
Cutting area: 39.4” d x 63” w (1000 x 1600 mm)
Cutting stroke: 4.3” (110 mm)
Power: 220-volt, 3-phase, 60-cycle
Condition
Rebuilt
Refurbished
Included
Single manual slide table
Polypropylene cutting pad
Safety guards
