NovaStar, BM108, 2025, Square Bottom Paper Bag Machine, 150 to 330mm Width, 60 to 150 GSM, 200 Bags/Min (New)

NovaStar, BM108, 2025, Square Bottom Paper Bag Machine, 150 to 330mm Width, 60 to 150 GSM, 200 Bags/Min

Description

  1. Overview
    1. BM108 – square bottom paper Bag machine
    2. Year: 2025
    3. State-of-the-art, roll-fed machine designed for efficient production of square bottom paper bags without handles
    4. Uses continuous rolls of paper, ideal for high-volume manufacturing in the food industry, retail packaging, and paper Bag manufacturing
    5. Advanced automation integrates paper feeding, tube forming, cutting, and bottom forming into a continuous online process, maximizing productivity and reducing labor costs
  2. Precision And Efficiency
    1. Equipped with a photoelectric detector for precise control over cutting length, ensuring high accuracy
    2. Handles very thin paper at fast speeds, optimal for industries demanding quick turnaround without compromising quality
  3. Advanced Control System
    1. Powered by a sophisticated Japanese Yaskawa electronic control system and servo motors
    2. Ensures stable, reliable operation with minimal maintenance, delivering consistently high-quality bags and boosting production efficiency
  4. Key Features And Units
    1. Paper material feeding and conveyance: roll-fed with automatic lifting function for easy paper roll changes
    2. Equipped with unwind air shaft and hydraulic cylinder lifting control
    3. Automatic tension control system ensures smooth, consistent feeding
    4. Paper Bag forming: precision gluing of paper edges and tube forming
    5. Four-cornered square bottom forming with accurate glue application
    6. Produces bags ready for collection or further processing
    7. Finished Bag collection: presses and conveys finished bags for smooth handling
    8. Integrated automatic counting system for inventory and packaging management
    9. Bag dimensions (length x width x bottom width): length 280 to 530 mm, width 150 to 330 mm, bottom width 70 to 180 mm
    10. Paper thickness range: 60 to 150 gsm
    11. Maximum production speed: up to 200 bags per minute
    12. Paper roll width: 470 to 1050 mm
    13. Paper roll diameter: up to 1500 mm
    14. Machine power: 38 V, 8 kW
    15. Machine weight: 8,000 kg
    16. Machine dimensions (length x width x height): 9500 x 2600 x 1900 mm
    17. High-speed production for large-scale Bag manufacturing
    18. Precision and reliability with advanced sensors and servo control
    19. Efficient roll-fed system reduces downtime during paper roll changes
    20. Consistent Bag quality suitable for food-grade and retail packaging
    21. Supports sustainability goals by enabling eco-friendly kraft paper Bag production
  5. Ideal For
    1. Flour mills and food packaging companies
    2. Retail packaging manufacturers
    3. Paper Bag producers aiming to expand capacity
    4. Businesses committed to replacing plastic with sustainable alternatives
  6. Specifications
    1. Voltage: 480V
