Multiline F, Airlay Forming System, 600 to 5000 GSM, 600 kg/h/m (New)

Overview

1. The airlay unit mod. F is a purely aerodynamic forming system.

2. It is the preliminary batt forming and feeding system for the following airlay carding units P or S, C or D.

3. Thanks to the weighing system in exit, PID control and possibility to adjust the formation chamber, the airlay F can also be used as an independent airlay forming system, bypassing the following airlay carding sections (when present).

4. Having no opening elements, the airlay unit F is suitable to form nonwovens from non-fibrous raw materials, such as foam pieces or fiber balls.

Specifications

1. Weight range: 600 to 5,000 gsm

2. Productivity: 600 kg/h/m

3. Fiber fineness: 0.9 to 500 den

4. Fiber length: 5 to 100 mm

5. Resins: no

6. Multiline: F

Compatible Fibers

1. Natural fibers: cashmere, coconut, cotton, juta, kenaf, wool, hemp, sugar cane, linen, sisal

2. Synthetic fibers: polypropylene, aramid, polyester

3. Regenerated fibers: mattress scraps, shoddy

4. Mineral fibers: carbon

Applications

1. Automotive

2. Technical felts

3. Filtration

4. Furniture

5. Mattress

6. Wadding

7. Abrasive web

8. Carpets

Production Capacity

1. Up to 500 kg/h/m
