Vecoplan, VAZ 1100 XL XR, 2023, Single Shaft Shredder, 60HP, 42x52 inch Cutting Area

Vecoplan, VAZ 1100 XL XR, 2023, Single Shaft Shredder, 60HP, 42x52 inch Cutting Area

Description

  1. Overview
    1. Never used, still in original crate
    2. Brand: Vecoplan
    3. Model: Vaz 1100 XL XR
    4. Year: 2023
  2. Specifications
    1. Infeed hopper: up to 80” x 71”, flared as required to accept material from a lift and dump
    2. Machine cutting area: 42” wide x 52” long ram dimension with abrasion resistant top plate, smooth interior to prevent material bridging
    3. Rotor profile: high capacity production cutting profile with full-load startup capability and self-cleaning rotor side pockets to reduce sidewall wear
    4. Rotor bearings: double spherical, tapered roller bearings in solid steel housings (not cast)
    5. Sizing screen: 1”, close-tolerance radius to prevent material blinding
    6. Infeed hopper: 3 – 3.5 cubic yard capacity, flared as required to accept loading
    7. Infeed system: PLC controlled 2 speed and dual pressure hydraulic ram, external ram guides for bridge-free interior and simplified maintenance
    8. Material containment: fully surrounded chamber, spring-loaded wipers for even wear
    9. Rotor: high torque setting, self-cooling profile, lifetime warranty
    10. Number of cutters: 48, concave profile, 4-way indexable, hardened compound, fully supported
    11. Rotor speed: 95 rpm, seamless gearbox on floating mount with fluid coupling connection
    12. Drive motor hp: 60hp, TEFC, premium efficiency, 1.15 service factor. Automatic shutoff when the machine runs empty
    13. System controls: Allen Bradley PLC controls package with display interface
    14. Machine weight: 7,000 lbs
    15. Voltage: 460V, 3ph, 60Hz
    16. Weight: 3175
  3. Safety Consideration
    1. This machine is fitted with exclusive milled rotor end pockets. This permanent feature is maintenance free over the life of the shredder and is designed to automatically expel trapped material and prevent excessive heat generation and sidewall wear
  4. Included Options
    1. XL-series machine frame package. This machine includes an oversized rotor diameter, higher motor drive power, a forward-sloped machine floor, easy-access screen doors with quick-release and gas-assisted opening, larger gearbox and hydraulics, and a high production rotor configuration
    2. 24” support base with safety transition for discharge onto conveyor
    3. Sand filled hopper for sound attenuation and hinged access door with safety interlock
    4. Acoustic foam filled hopper hood
