W&H, Matador NP 38, 2000, Flat and Satchel Bag Machine, Bag Width 60-380mm, Max Speed 1200 bags/min

W&H, Matador NP 38, 2000, Flat and Satchel Bag Machine, Bag Width 60-380mm, Max Speed 1200 bags/min Sold

Description

  1. Overview
    1. W&H Germany
    2. Year of production: 2000
    3. Machine still at work (from time to time)
    4. Machine is stopped, still connected to power
  2. Working Range
    1. Bag width with flat bags: 60 to 380 mm
    2. Bag width with gusseted bags: 60 to 380 mm
    3. Cut-off length with 2 pairs of folding tongs: 180 to 300 mm
    4. Cut-off length with 1 pair of folding tongs: 310 to 600 mm
    5. Gusset depth with max. bag width: max. 70 mm
    6. Flap size: 0 to 15 mm
    7. Bottom folder: 15 to 30 mm
    8. Reel width: max. 1060 mm
  3. Materials
    1. Paper: 30-100 g/sq.m
    2. Glassine, parchment, supported
    3. Aluminum foil: min. 40 g/sq.m
    4. Can produce bags with foil window
  4. Output
    1. The maximum speed will depend upon the type of material handled, the machine outfit and the number of folding tongs used
    2. Max. bags/min with 2 sets of folding tongs: 1200
    3. Max. bags/min with 1 set of folding tongs: 600
    4. Output with in-line bag packer: max. 800 bags/min
  5. Space Required
    1. Length: 8500 mm
    2. Width: 2500 mm
    3. Height: 2000 mm
    4. Weight: approx. 5.8 t
  6. Electrical Installation
    1. 12.2 kW
  7. Specifications
    1. Weight: 5800
