Number of spindles: 10n, 100 spindles are standard
Spindle gauge: 300 mm, 366 mm optional
Spindle speed range: 2500 to 6000 r/min
Twist range: 65 to 500 t/m
Twist direction: s or z
Spindle tensioner: ball type
Traverse: 150 mm to 250 mm (optional according to actual situation)
Rated power: 24 kW
Start-up mode: frequency conversion slow start
Take-up angle: 0 to 30°
Take-up speed: max. 120 m/min
Take-up package: max. 5 kg (depends on the process parameters)
Spindle drive: apron belt circulation drive
Application
Applied to make yarns twisted in the low and medium tpm
Applied for making twist of single-ply and multiplied yarns of dty, poy, fdy, viscose rayon etc in yarn count 75d-1000d
Features
Convenient operation, reasonable transmission, compact construction and attractive appearance
Flexible option on single spindle’s packaging edge; also flexible operation on put on/take off taking-up bobbins
Can possibly omit troubles that other two-for-one twisters need to divide into small yarn cones to produce; the processes don’t need that so its process is decreased and easy, the efficiency and yarn quality can be improved also
Manual renegade spindle-braking system is easier to operate, and also it can extend the life of belt and spindles
