MAN, MGT6000-1S, Gas Turbine Generator Package, 6.5 MW, 50 Hz, 10.5 kV

Description

Overview
1. Quantity: three (3) MAN MGT6000-1S industrial gas turbine generator packages (6.5 MW x 3 = 19.5 MW)
2. Each unit is a complete 6.5 MW class power generation package configured for 50 Hz operation and includes the full MAN ES base module, top module and auxiliary systems
3. Condition: new, unused packages
4. Complete plug and play; available immediately
Specifications (Per Unit)
1. Electrical output: 6.5 MW (nominal), derived from 8.14 MVA at PF 0.80
2. Frequency: 50 Hz
3. Voltage: 10.5 kV
Package Contents (Each Package)
1. MAN MGT6000-1S industrial gas turbine (axial exhaust)
2. Synchronous AC generator, 8.14 MVA, 10.5 kV, 50 Hz, 1500 rpm
3. Base frame with integrated lube oil tank
4. Load gear, subsystems and auxiliary equipment
5. Acoustic enclosure for turbine and generator
6. Control system and low-voltage switchgear
7. Air intake system, turbine intake and enclosure ventilation (top module)
8. Off-package fire extinguishing and monitoring systems
Delivery
1. 4-6 weeks preparation from order acknowledgement

HS code	8502.39

Speed (RPM)	1,500 rpm
