Soma, T41-40, 2011, Slitter-Rewinder, Width 1600mm, Max Speed 800 m/min

Soma, T41-40, 2011, Slitter-Rewinder, Width 1600mm, Max Speed 800 m/min

Description

  1. Overview
    1. Floor pick-up configuration
    2. Separate unwinding station
    3. Turret rewinding station
    4. Two turret rewinding shafts
    5. Core positioning via laser
    6. Automatic unload of rewind rolls
  2. Specifications
    1. Material width: 350 mm to 1600 mm
    2. Unwinder diameter max. 1200 mm
    3. Rewind diameter min. 200 to 800 mm
    4. Min. slit width: 35 mm
    5. Machine speed, max: 800 m/min, 20-200 gr
    6. 20 pcs. knives with automatic setting
