NovaStar, FN434, CNC Foam Contour Horizontal Wire Blade Cutting Machine, Width 2200mm, Manual Rotary Table, 8.0kW (New)

NovaStar, FN434, CNC Foam Contour Horizontal Wire Blade Cutting Machine, Width 2200mm, Manual Rotary Table, 8.0kW

Description

  1. Overview
    1. Cnc foam contour horizontal wire blade cutting machine with manual rotary table, width 2200mm
  2. Specifications
    1. Max cutting length: 2200mm
    2. Max cutting width: 2200mm
    3. Max cutting height: 1250mm (40hq) or 1150mm (20gp container)
    4. Machine table: carrousel turning
    5. Cnc system: yes
    6. Cutting speed: 0-2.0m/min (hard material)
    7. Cutting precision: ±1.0mm
    8. Blade size: 10800mm x 1.20mm
    9. Blade pressure: 0.6mpa
    10. Blade journey: 48mm, 50hz
    11. Vibrating tool linear speed: 3000mm/s
    12. Cutter broken protect: yes
    13. Operation option: modem (remote diagnose and maintenance), auto programming software, computer operation table
    14. Power supply: 380v, 3 phase, 50hz
    15. Total motor power: 8.0kw
    16. Machine weight: 2200kg
    17. Machine external size: l5000 x w3500 x h2200mm
  3. Condition And Warranty
    1. Machine warranty: 1 year
  4. Shipping Information
    1. Shipping size: 20cbm, 2200kg
    2. Shipping dimension: 20cbm, 2200kg, 4 package (20gp)
