NovaStar, GN132, New, Hydraulic Horizontal Baler, 1100x2000mm Inlet, 4 to 6 Bales/Hr, 1800kN (New)

NovaStar, GN132, New, Hydraulic Horizontal Baler, 1100x2000mm Inlet, 4 to 6 Bales/Hr, 1800kN

Description

  1. Overview
    1. Hydraulic baler, model GN132.
    2. Working pressure: 1800 kN.
    3. Feeding inlet size: 1100 x 2000 mm.
    4. Bale output type: automatically pushing bale.
    5. Bundling type: manually threaded steel wire.
    6. Strapping line (iron wire): 4 lines, Ф3.5 mm (10#) or 2.8 mm (0.1 in) (12#).
  2. Specifications
    1. Bale size: 1100 mm (43.3 in) (W) x 850 mm (33.5 in) (H) x 600 mm (23.6 in) (L).
    2. Capacity: 4 to 6 bales per hour.
    3. Density: 300 to 400 kg/m³, depending on raw material moisture.
    4. Main oil cylinder: Ф250.
    5. Oil cylinder stroke: 4200 mm (165.4 in).
    6. Main motor: 37 kW (49.6 hp) + 5.5 kW (7.4 hp), Wanan brand.
    7. Conveyor: 2 units, each 10.5 m (34.4 ft) (W x L), 5.5 kW (7.4 hp), Wanan brand.
    8. Volume of hydraulic cylinder: 1.6 m³ (56.5 cu ft).
    9. Volume of cooler: 8 m² (86.1 sq ft).
    10. Voltage: 230 V / 60 Hz / 3-phase.
  3. Control and Components
    1. Operation type: PLC electric control cabinet and remote-control unit.
    2. PLC: Mitsubishi or Siemens.
    3. Touch screen: Mitsubishi or Siemens.
    4. Main electrical component: Schneider or Omron.
    5. Main hydraulic module: cartridge valve.
    6. Cooler: fan cooling, used for hot days.
