Cummins, 100 kW Generator

Cummins, 100 kW Generator

Description

  1. Boiler
    1. Make: CVPL
    2. Capacity: 48 TPH
    3. Type: Single drum water tube AFBC
    4. Design pressure: 65 kg/cm2
  2. Induced Draft Fan (quantity: 2)
    1. Make: CVPL
    2. Type: Centrifugal
    3. Specified operating flow: 61705 nm3/hrs
    4. Design capacity: 77131 nm3/hrs
    5. Design head: 200 mmwc
    6. Fan rated speed: 960 rpm
    7. Motor rating: 110 kW
  3. Forced Draft Fan (quantity: 2)
    1. Make: CVPL
    2. Type: Centrifugal
    3. Specified operating flow: 58387 nm3/hrs
    4. Design capacity: 72984 nm3/hrs
    5. Design head: 800 mmwc
    6. Fan rated speed: 1440 rpm
    7. Motor rating: 250 kW
  4. P. A. Fan (quantity: 2)
    1. Make: CVPL
    2. Type: Centrifugal
    3. Specified operating flow: 3788 nm3/hrs
    4. Design capacity: 4735 nm3/hrs
    5. Design head: 700 mmwc
    6. Fan rated speed: 1440 rpm
    7. Motor rating: 45 kW
  5. Boiler Feed Pump (quantity: 2)
    1. Make: KSB / Sulzer
    2. Type: Horizontal multistage centrifugal pump
    3. Design capacity: 64.76 nm3/hrs
    4. Fan rated speed: 2900 rpm
    5. Motor rating: 250 kW
    6. Model: MC 80/13
  6. Turbine
    1. Make: Triveni
    2. Power: 10.5 MW
    3. Inlet steam flow: 45050 kg/hr
    4. Inlet steam temperature: 495 +/- 5 degree Celsius
    5. Inlet steam pressure: 64 kg/cm2
    6. Speed: 6827 rpm
    7. Type: Bleed cum condenser turbine
    8. Manufactured year: 2007
    9. Model: SCG-3-52
  7. Alternator
    1. Make: TDPS - Toyo Denki Power System
    2. Output: 13125 KVA
    3. Type: TC145
    4. Capacity: 10.5 MW
    5. Voltage: 11 kV
    6. Current: 689 A
    7. Speed: 1500 rpm
    8. Manufactured year: 2007
  8. Ash Handling System (ECO, APH, ESP)
    1. Make: Mecawber Beekay Pvt. Ltd
    2. Collaborator: Clyde Bergemann Materials Handling Ltd, U.K.
  9. ACC
    1. Make: Paharpur
    2. Turbine exhaust flow rate: 41 TPH
    3. Guaranteed back pressure: 0.18 KSCA
    4. Exhaust steam enthalpy: 585 kcal/kg
    5. Heat rejected: 21711550 kcal/hr
    6. Overall heat transfer coefficient: 27.98 kcal/hr sq m degree C
    7. LMTD: 8.14 degree C
    8. Motor rating: 120 kW
  10. ESP
    1. Make: CVL
    2. Type: Horizontal flow dry type
    3. Number of collecting electrodes: 432
    4. Number of emitting electrodes: 408
    5. Transformer: Step up double wound 440V/120kV, 650 mA secondary current
    6. ESP controller panel make: ADOR Powertron Ltd
    7. Manufactured year: 2006
