NovaStar, MS520, Fabric Edge Guiding System, DC 24V, 0.5 mS Response Time (New)

NovaStar, MS520, Fabric Edge Guiding System, DC 24V, 0.5 mS Response Time

Description

  1. Servo Web Guide Controller Technical Parameters
    1. Model number: MS520
    2. Control method: DC servo driver
    3. Power: DC 24V /5A
    4. Control input: DC 0~5A
    5. Control output: 24V, PWM
    6. Response time: 0.5 mS
    7. Environment temperature: -10~60C, below RH90%
    8. Weight: 1.2 kg
  2. Color Sensor Technical Parameters
    1. Color sensor: PS-400/US-500
    2. Power supply: DC-12V
    3. Power output: DC 0-5V
    4. Detective range: 5mm
    5. Detective accuracy: 0.1mm
    6. Detector methods: ultrasonic exposure
    7. Frequency: 100KHZ
    8. Shell material: aluminum alloy
  3. Servo Actuator Parameters
    1. Model number: PD-204L150
    2. Max thrust N (Kgf): 200 (150)
    3. Max weight: 2000 kg
    4. Rod stroke: 150mm (+-75mm)
    5. Max driving speed: 40mm/s
  4. Application
    1. Textile machinery: fiber twisters, treatment machines, weaving machines.
    2. Metal fishing systems: extruders, wire stretchers, presses, welders, steel wire retractors, cutters, pipe makers, wire winding machines.
    3. Machine tool systems: lathes, millers, steel extruders, CNC lathes, specialized machinery.
    4. Transportation equipment: hoists, feeders, conveyors, rollers, winders.
    5. Paper-making systems: bag-making machines, box-making machines, slitters, book-making machinery, cutters, copy paper machines.
