NovaStar, AT105, Robotized Mattress Manufacturing Robot, 6-Axis, 3.1m Arm Range, 220kg Max Load, 22kW (New)

NovaStar, AT105, Robotized Mattress Manufacturing Robot, 6-Axis, 3.1m Arm Range, 220kg Max Load, 22kW

Description

  1. Overview
    1. 6-axis robot with 6 motors
    2. Arm range of 3.1 meters
    3. Maximum lift height of 3.1 meters
    4. Lowest position is 0, allowing placement on the ground
  2. Specifications
    1. Maximum load weight: 220 kgs
    2. Total power: 22 kW
    3. Speed: when clamping mattress panels, cycle time is approximately 10 to 15 seconds per operation
