Siemens, SGT-500, 2007, Gas Turbine Package, 17.4 MW, Dual Fuel, 50/60 Hz

Siemens, SGT-500, 2007, Gas Turbine Package, 17.4 MW, Dual Fuel, 50/60 Hz

Description

  1. Overview
    1. Two units offered together: turbine and gearbox only.
    2. Manufactured in 2007.
    3. New surplus, never used, zero operating hours.
    4. Stored strictly in accordance with OEM preservation procedures, and maintained and rotated in storage per the Siemens protocol.
    5. Originally supplied for an FPSO project that was cancelled.
    6. No alternator and no auxiliaries; the electrical generator is quoted separately.
  2. Gas Turbine, Technical Data
    1. Model: Siemens SGT-500.
    2. Configuration: single-shaft industrial gas turbine.
    3. Fuel: dual fuel, natural gas or diesel.
    4. Frequency capability: 50 / 60 Hz. The turbines and gearbox are set to 60 Hz.
    5. Power output at ISO conditions, indicative: approximately 17.4 MW on natural gas and approximately 17.0 MW on diesel. Output may be slightly higher depending on site conditions.
    6. Specific fuel consumption: 221 g/kWh on natural gas, 262 g/kWh on diesel.
    7. Heat rate: 11,066 kJ/kWh on natural gas, 11,200 kJ/kWh on diesel.
  3. Gearbox
    1. Manufacturer: Flender Graffenstaden, France.
    2. Rated power: 22,500 kW.
    3. Supplied complete with couplings and coupling guards.
  4. Lube Oil System
    1. Manufacturer: Flenco Group.
    2. Marine rated.
    3. Complete lube oil system included.
    4. Fin-fan type lube oil cooler included.
  5. Certification
    1. Marine rated.
    2. DNV (Det Norske Veritas) certified.
  6. Scope of Supply, Skid-Only Package
    1. SGT-500 power turbine.
    2. Intake and exhaust system.
    3. Lubricant oil system.
    4. Liquid fuel system.
    5. Fuel forwarding pump skid.
    6. Gas fuel system.
    7. Gear system: gearbox with coupling and coupling guards.
    8. Compressor wash system.
    9. Air intake system: turbine combustion air inlet casing.
    10. Exhaust system: exhaust plenum.
    11. Cooling system: fin type lube oil cooler.
    12. Complete lube oil system.
    13. Base frame, enclosure and platform.
  7. Condition and Availability
    1. New surplus, zero operating hours.
    2. Quantity: two units.
    3. Warranty: twelve months or 8,000 hours through a Siemens shop.
    4. Available for immediate shipment.
