NovaStar, GC155, Automatic Non-Woven Perforating and Folding Machine, 200mm Width, Z Fold, 350 pcs/min (New)

NovaStar, GC155, Automatic Non-Woven Perforating and Folding Machine, 200mm Width, Z Fold, 350 pcs/min

Description

  1. Overview
    1. Folding type: Z fold
    2. Production speed: 300 to 350 pieces per minute
  2. Specifications
    1. Width of raw materials roll: 200 mm (according to client request)
    2. Diameter of raw material roll: 1100 mm (according to client request)
    3. Gammage of raw material: 15 g per m2 to 80 g per m2
    4. Unfolded size of product: L 200 mm x W 100 to 200 mm
    5. Folded size of product: 100 mm to 200 mm x 100 mm (L x W)
    6. Power supply: 220 V, 60 Hz, 3 phase, 3.0 kW
    7. Machine size: 3300 mm x 900 mm x 1400 mm (L x W x H)
    8. Machine weight: 650 kg
