NovaStar, NF169, High-Speed Elastic Tapes Making Machine, 60 Spindle, 3mm Diameter, 220V (New)

NovaStar, NF169, High-Speed Elastic Tapes Making Machine, 60 Spindle, 3mm Diameter, 220V

Description

  1. Overview
    1. Type: Two sides and one layer
    2. Needle no: 6 N
    3. Tape shape: Round, diameter 3 mm
    4. Material: Nylon 140D + spandex 140D
  2. Specifications
    1. Overall dimension: L 6780 mm x W 1110 mm x H 1700 mm
    2. Each section length: 2200 mm
    3. Section no: 3 sections
    4. Spindle no: 60 spindles
    5. Each section spindle no: 20 spindles per section
    6. Spindle gauge: 3000 rpm (max)
    7. Main motor: (2 motors) 2.2 + 0.5 kW
    8. Voltage: 220 V, 60 Hz, 3 phase
