NovaStar, QL270, Computerized Single Head Quilting Machine, 3000 RPM, 15cm Head Lift-up, 5 Panasonic Servo Motors (New)

NovaStar, QL270, Computerized Single Head Quilting Machine, 3000 RPM, 15cm Head Lift-up, 5 Panasonic Servo Motors

Description

  1. Overview
    1. 1:1 frame fixed structure, most compact machine design.
    2. Fixed quilting frame; sewing head moves in x direction and saddle tree moves in y direction.
    3. Maximum quilting area with minimum requested installation area; solves the problem of traditional machines that occupy 2 to 4 times the space of moving frame models.
    4. Head lift-up of 15 cm.
    5. Sewing head lifts up automatically up to 15 cm after finishing quilting.
    6. Easy to change the frame at any stop point; easier to move head for jump pattern and thicker material pattern.
    7. Able to work two small quilts jumping from one to another from the aluminum border frame.
  2. Computer System
    1. 10.4 inches touching screen computer, user friendly.
    2. Easier and simplified operation; reliable computer control system.
    3. Automatic thread trimming function.
    4. Thread breakage detection; machine will automatically stop once thread gets broken.
    5. Remembers stop position and automatically back to the stopping point to continue sewing.
    6. Emergency stop by one push on button.
    7. Enhancing sewing by back stitches when start or finish a pattern.
    8. Stitch length definable, angle compensation, pattern zoom in/out.
    9. Speed automatic adjustable control; able to make sharp angle or control sewing quality as demands.
    10. Automatic needle and rotary hook positioning adjustment control by computer to ensure high precision stitch quality.
    11. Jump quilting function for independent design.
    12. Stitch statistic to count machine output.
    13. Set bobbin change time by stitch or sheet number; machine stops automatically to change bobbin before bobbin thread runs out.
    14. Storage capacity is 300,000 stitches up to 200 patterns.
    15. Supports popular quilting design formats.
    16. English and other special languages are available upon request.
    17. Power failure protection.
    18. Usb or wifi (optional) input pattern; large size pattern can be read.
  3. Optional Configuration
    1. Safety protection: infrared facility increases safety factor (option); working area protection from two side and back side of machine.
    2. Easy frame changer: double layers frame changer for preparing material and changing quilt frames easily; adjustable and extendable aluminum quilting frames; the size of frame can be adjusted freely according the production demand.
    3. Automatic frame changer: frame up and down drive by motors automatically; easy to feed quilt frames to the quilting machine with just a breeze push; operate by one person easily which decreases the workload.
    4. Wifi/usb pattern transfer: optional wifi pattern transfer devices; able to transfer patterns directly from office computer control system to quilting machine.
  4. Specifications
    1. Capacity: 3000 RPM
