NovaStar, DT183, 150 Tons, 1050x2000mm Cutting Area, 4 Columns, 2 Cylinders (New)

NovaStar, DT183, 150 Tons, 1050x2000mm Cutting Area, 4 Columns, 2 Cylinders

Description

  1. Overview
    1. Cutting force: 150 tons
    2. Columns: 4
    3. Cylinders: 2
    4. Stroke: 50 to 250 mm
    5. Rated power: 11 kW
    6. Cutting area: 1050 x 2000 mm
    7. Weight: 6600 kg
    8. Voltage: 220 volts, 3-phase, 60 or 50 Hz
  2. Operating Conditions
    1. Humidity of work place: 10% to 90%
    2. Temperature of work place: 10°C to 45°C
    3. Working time: 24 hours/day, 6 days/week
  3. Technical Specifications
    1. Effective working area: 1050 mm x 2000 mm
    2. Stroke: 50 to 250 mm
    3. M. C. F: 1500 kN (150 tons)
    4. Control requirements: Program control, digital readout (PLC+HMI control mode)
    5. Maximum oil pressure: 200 kgf/cm²
    6. Control mode: Manual/automatic switching control mode is available on both the operation panel and touch screen. Set the working height and cutting depth on touch screen. Emergency stop device on main control panel for emergency response.
    7. Equipment running noise: 60 dBA ±10 dBA
    8. Impact style: Automatic cutting from top to bottom
    9. Feeding way: The motor drives the double chain, automatic return type guide feed, feeds quietly, smoothly, precisely and lightly.
    10. Feeding speed: 20 to 25 times/minute
    11. Accessory device: The clamping mechanism of die
  4. Memory and Protection of Cutting Die
    1. The machine is equipped with automatic setting function of cutting die.
    2. The numerical control system can memory the shape of cutting die which is needed during work, and does not need to reset the shape when change the cutting dies.
    3. The cutting die is provided with sensor protection device.
  5. Hydraulic and Electrical Systems
    1. Hydraulic device: The hydraulic device is equipped with cooling device (water-cooling), filter device of oil returning and inletting.
    2. Electrical control cabinet: It incorporates sealed type, heat dissipation and filter screen, and is equipped with tri-color signal light (power, regular work, unit exception).
  6. Safety and Protection
    1. Security protection setting: Double position with emergency stop button.
    2. Machine protection: Motor overload protection, cutting pressure control table, pressure-overload protection, earth leakage protection, ground protection.
    3. Alarm picture: Equipment scram, motor overload, oil pressure too low or too high, the oil temperature is too high, etc.
  7. Lubrication and Maintenance
    1. Lubricating oil supply: When the machine runs for ten minutes, the lubricating oil will be replenished automatically.
    2. Design layout: The hydraulic system of the whole machine is outside the machine, so that it is convenient to maintain the machine. The body of machine is fixed by the footing and attached with shock absorber.
  8. Equipment Appearance and Color
    1. Color of equipment: Color of machine body according to customer requirements.
    2. Equipment appearance: The surface of equipment without obvious oil stain when it is operating and static.
  9. Included Accessories and Documentation
    1. Accessories: Plastic plate 1 piece, pad 4 pieces, tool wrench 1 set, instruction manual.
    2. The content provided with the equipment when delivered: Equipment (important components) specification (maintenance method, safety factor, mechanical and electrical schematic diagram, electrical program), common exception handling methods, technical parameters, operational approach, consumable parts list.
