NovaStar, Meltblown Line, 1750mm Trim Width, 100 m/min, 180 kg/h

NovaStar, Meltblown Line, 1750mm Trim Width, 100 m/min, 180 kg/h

Description

  1. Overview
    1. 1750 mm final trim width (68 inches)
    2. Produces 1 to 5 micron (even under 1 micron)
    3. Range of gsm: produces 15 to 300 gsm
    4. Product application: medical and filtration
    5. Fiber type to be processed on the line: PP chips
    6. Has cooling calendar
    7. Has winder with slitters
    8. Containers to ship approximately: 15 containers 40” OT (there may be needed some HC or out of gauge containers)
  2. Technical Specification
    1. Project data
    2. Final product weight: 15 to 300 gsm
    3. Final product width: 1750 mm trimmed
    4. Final roll diameter: 1200 mm maximum
    5. Throughput meltblown: maximum 180 kg/hour
    6. Production speed: maximum 100 meters per minute
    7. Labeling of machines: English
    8. Standards: DIN-ISO-IEC-VDE
    9. Indication units: metric
    10. Execution: machine directive 2006/42/CE
    11. Power supply: 480 volts AC ± 5% 60 hertz, 3 phases supply TN (neutral solidly earthed)
    12. Voltage for auxiliary switches: 220 volts AC single-phase
    13. Control voltage: 24 volts DC for power supply to: PLC, I/O input-output, safety and guarding related systems
    14. Motors: protection/insulation class: AC motors IP54
    15. Electrical cabinets room: from +10°C, to a maximum of +40°C with an average value over 24 hours ≤ 35°C during production time
    16. Altitude: up to 500 meters above sea level
  3. Production Room Conditions
    1. In-room temperature: 25 °C in summer and 20 °C in winter
    2. Moisture: 50/60%
    3. Temperature during erection: minimum 18 °C
    4. Air conditioning of the building: needed
    5. Room pressure: ≥5 Pa
    6. Crane: 1 crane, capacity 10 ton each, stroke hook to floor 5 meters per minute
    7. Minimum compressed air pressure: 6.0 bars at the machine – clean and dry
  4. Colors
    1. Machines external structure: light grey – RAL 7035
    2. Motors: original manufacturer’s colors
    3. Operator control desk: light grey RAL 7035
    4. Electrical cabinets: light grey RAL 7035
  5. Technical Documentation
    1. The following manuals are supplied in Italian language:
    2. Layout drawing
    3. Floor load drawing
    4. One set of electrical schematics for each machine
    5. HMI operation manual
    6. Electrical drawings
    7. Lubrication/service manual
    8. Safety documents
    9. Spare part list
  6. Condition
    1. Status: assembled, it can run
    2. Production year: the line has been produced in September 2020 and it has been in production only for one year
