NovaStar, EC143, Environmental Stress Screening Test Chamber, 1000 Liters, -70 to 100 C, 1000x1000x1000mm (New)

NovaStar, EC143, Environmental Stress Screening Test Chamber, 1000 Liters, -70 to 100 C, 1000x1000x1000mm

Description

  1. Overview
    1. Environmental stress screening test chamber is a 1000 liter test chamber equipped with a wide range of temperatures (-70 °C to 100 °C).
    2. It comprises a 3 level overheating protection device designed to meet comprehensive test conditions of temperature to test product defects and production flaws.
    3. Used to detect production flaws by military, aerospace industry and electronic manufacturers to determine environmental adaptability and service life of a product.
  2. Features
    1. Wide temperature range (-70 °C to 100 °C).
    2. Standard refrigeration system (semi-hermetic compressor).
    3. Touch screen interface panel.
    4. 2 access cable ports.
    5. 3 level overheating protection device.
    6. High testing precision.
    7. Large observation window.
    8. Water and electricity separation design.
  3. Specifications
    1. Chamber capacity: 1000 L.
    2. Temperature change rate: 10 °C / min.
    3. Interior dimension (W x H x D): 1000 x 1000 x 1000 mm.
    4. Exterior dimensions (W x H x D): 1600 x 2200 x 2000 mm.
    5. Temperature range: -70 °C to 100 °C.
    6. Rapid temperature change: -55 °C to 85 °C.
    7. Control system: full linear control.
    8. Constant temperature: ± 0.5 °C.
    9. Temperature deviation: ± 3.0 °C.
    10. Compressor: semi-hermetic compressor.
    11. Cooling mode: water cooled.
    12. Cooling system: balanced temperature and humidity control system.
    13. Heater: iron-chrome wire heater.
    14. Blower: centrifugal blower.
    15. Temperature sensor: PT100 platinum resistance thermometer sensor.
    16. Controller: touch screen programmable controller.
    17. Ambient temperature: 10 °C to 35 °C.
    18. Power supply: AC 380 V ± 10 % 50 Hz or 220V 50/60Hz.
    19. Exterior material: cold-rolled steel sheet (rust proof and plastic spray treated) / stainless steel.
    20. Interior material: stainless steel plate (SUS 304).
    21. Insulation material: rigid polyurethane foam and glass wool.
    22. Observation window: glass incorporating heat generator.
    23. Weight: 1800 kgs.
